进口造水机淡水流量计ASAHI OTOYO KIKO, ASAHI OSAKA KIKO, 13mm, 15mm
Brand：ASAHI
Service: FWG，FRESH WATER GENERATOR
Name: WATER FLOW METER
Nominal size: 13mm, 15mm
Flow Range: 30L/h - 3m3/h, Qn 1.5m3/h
Nominal Pressure.: PN 10 bar
Min/Max Temperature: 0.1/50 ℃
Counter: Mechanical type
Body Material: Brass
Connection Thread on Body: G3/4"
Overall Length: 100mm
ASAHI SANWA MADE INTHAILAND
|
替换ALFA LAVAL造水机淡水流量计98542600-03, 98542600-04
1、产品型号Model: WFM-15
Replacement for: ALFA LAVAL 98542600-03, 1/2" BSP, EVW-DK 1/2"
Nominal size: 1/2"
Flow Range: 31.25L/h - 3.125m3/h, Qn 1.5m3/h, Q3 2.5m3/h
Nominal Pressure.: PN 16 bar
Min/Max Temperature: 0.1/90℃
Counter: Mechanical type
Body Material: Brass
Connection Thread on Body: 3/4" BSP
Overall Length: 110mm
Connection Pipe Thread: 1/2" BSP
2、产品型号Model: WFM-20
Replacement for: ALFA LAVAL 98542600-04, 3/4" BSP, EVW-DK 3/4"
Nominal size: 3/4"
Flow Range: 50L/h - 5m3/h, Qn 2.5m3/h, Q3 4m3/h
Nominal Pressure.: PN 16 bar
Min/Max Temperature: 0.1/90℃
Counter: Mechanical type
Body Material: Brass
Connection Thread on Body: 1" BSP
Overall Length: 130mm
Connection Pipe Thread: 3/4" BSP
|
