我公司正排量容积式流量计Positive Displacement Flow Meter完全替换日本日东精工株式会社NITTO SEIKO CO., LTD Slide Vane Flow Meter (SS TYPE)。总长度一致,法兰标准一致,功能一致。无需改动管道、法兰,或接线,完美替换。
MODEL: SSA0100B0FFM43450010R:SIZE 100mm,JIS10K Flange,MAX.?FLOW 150 m3/H., PRESS: 1.0 MPa,TEMP: 80℃。FUEL OIL FLOWMETER,NITTO SEIKO CO., LTD,SLIDE VANE FLOW METER (SS TYPE),本型号替换流量计为机械计数器,高周波式パルス発信器High frequency pulse,1L/P,供电电源12V/24VDC。
MODEL: SSA0150A00FFM43450010R:SIZE 150mm,JIS10K Flange,MAX.?FLOW 200 m3/H., PRESS: 1.0 MPa,TEMP: 80℃。FUEL OIL FLOWMETER,NITTO SEIKO CO., LTD,SLIDE VANE FLOW METER (SS TYPE),本型号替换流量计为机械计数器,高周波式パルス発信器High frequency pulse,1L/P,供电电源12V/24VDC。
|
我公司椭圆齿轮流量计OVAL GEAR FLOW METER完全替换日本TOKICO Flow Meter (SS TYPE)。总长度一致,法兰标准一致,功能一致。无需改动管道、法兰,或接线,完美替换。
MODEL: :SIZE 100mm,JIS10K Flange,MAX.?FLOW 150 m3/H., PRESS: 1.0 MPa,TEMP: 80℃。FUEL OIL FLOWMETER。本型号替换流量计为机械计数器,高周波式パルス発信器High frequency pulse,1L/P,供电电源12V/24VDC。
MODEL: :SIZE 150mm,JIS10K Flange,MAX.?FLOW 200 m3/H., PRESS: 1.0 MPa,TEMP: 80℃。FUEL OIL FLOWMETER,本型号替换流量计为机械计数器,高周波式パルス発信器High frequency pulse,1L/P,供电电源12V/24VDC。
|
|
|
我公司燃油粘度计在基本型基础上,加配一个改装适配器retrofit adapter,就可以升级、改造、替换V92系列毛细管粘度计Capillary type viscosity sensor,V12 Pneumatic Viscotherm,V52 Viscotherm等。
1.原V92毛细管粘度计配套电子式变送器,可以利用原粘度控制器,原电动调节阀。原V12毛细管粘度计配套气动式变送器,需要同时替换原气动粘度控制器为我公司电子式粘度控制器,替换原气动调节阀为电动调节阀,原配气管路不再需要。
2.我公司粘度计供电电源为24VDC,我公司电子式粘度控制器供电电源为220VAC
3.粘度量程一致 (0-25 mPa.s or 0-50 mPa.s)
4.粘度、温度2个 4-20mA输出一致
5.我公司粘度传感器与接线盒分开设计,电子线路板避开高温,使用寿命更长,性能更稳定
6.使用改装适配器,替换原毛细管粘度传感器时:
6-1. Remove items ②, ③, ⑤, ⑥, ⑦, ⑧, ⑨, the housing ① and optional thermometer ④ are left.
6-2, The retrofit adapter matches with the housing.
6-3. The Viscomaster is fitted into the adapter.
6-4. Install Interface Box in appropriate locations.
6-5. Wiring, 24V DC power supply and output signal.
型号Model: DG series
1. Viscosity and Temperature Sensor
Viscosity Measuring Range: 0-25 mPa.s or 0-50 mPa.s
Viscosity Accuracy: ±2% instantaneous or 0.5cst
Temperature Measuring Range: 0-200℃
Temperature Accuracy: ± 1 ℃
Temperature Transmitter: Pt100 Element
Max Operating Temperature: 180℃
Max Pressure: 105bar (1450psi)
Measuring Principle: Vibrating Tuning Fork Type
Sensor Material: 316L Stainless Steel
Vibrating Tine Finish Material: DLC (Diamond-like Carbon coating0
Process connection: 1.5" Cone seat
Signal Cable Length: 5 metres, integrated with sensor
Protection Class: IP65
Weight: Approx. 2 kg
2. Retrofit Adapter
Material: Carbon Steel
Process Connection: Applicable to V92,V12,V52 flange
Weight: Approx. 5 kg
3. Interface Box
Box Material: Cast Aluminium
Dimension(L×W×D): 250×120×82 mm
Mounting: Wall Mounting
Input Signal: From Sensor
Output Signal:
---- Viscosity: Active 4-20mA → 0-25 mPa.s or 0-50 mPa.s, current loop
---- Temperature: Active 4-20mA → 0-200 ℃, current loop
Response Time: Less than 3 minutes
Communication Interface: RS485 Modbus
Supply Voltage: 10-28VDC(typical 24VDC), Max 4 W
Cable Connection:
---- 1 * M16×1(Input Signal)
---- 1 * M20×1.5(Output Signal)
---- 1 * M20×1.5(Supply Voltagel)
Protection Class: IP65
Ambient Temperature: - 20 - + 55℃
Weight: Approx. 3 kg
|
可升级、改造、替换:
VAF Viscotherm V92系列毛细管粘度计Capillary type viscosity sensor
VAF Viscotherm Series V92 Model VC Electronic Component System
VAF Viscotherm sensor Series V92 Model EHC毛细管粘度计
VAF Viscotherm Series V12 Pneumatic System
VAF Instruments V52 VISCOPAK SYSTEM
an in-line automatic control System for the viscosity of heavy fuel oil
|
|
|
//////////////////////////////
//////
/
///////////
///////
//////
/////////////
|
/////////////////////////
//////
/
///////////
///////
//////
/////////////
|
|
|
/////////////////////////////////// |
////////////////////////////) |
|
|
/////////////// |
////////// |
